- L.O.A.: 47′-7″ ( 14.51M )
- L.O.H.: 44′-44″ ( 13.69M )
- L.O.D.: 43′-6″ ( 13.26M )
- L.W.L.: 42′-4″ ( 12.90M )
- Beam (over all W/ rub rail): 15′-8″ ( 4.78M )
- Draft to Keel ( Full load ): 5′-0″ ( 1.52M )
- Displacement ( Full load ): 56,100 lbs.
- Ballast: 3,000 lbs.
- Fuel Capacity: 1,000 USG
- Water Capacity: 290 USG
- Holding Tank Capacity: 60 USG
- Top Speed: 10 Kts
- Cruising Speed: 8.5 Kts
- Bridge Clearance Mast Up: 23′-3″
- Bridge Clearance Mast Down: 13′-9″
- Standard Power: Commins 6BT5.9M 210 hp @2600 RPM Intermittent Duty
|
